Reelcraft CA33118 L Hand Crank Hose Reel

Reelcraft CA33118 L Hand Crank hose reels are designed for rugged, heavy duty applications requiring long lengths of hose and large storage capacity. All-bolted unitized construction with no welds to fatigue, full flow swivel and heavy gauge steel frame, spool and drum ensure longest service life. Series 30000’s vibration-proof, self-locking fasteners are ideal for industrial or field use such as turf care or pest control.

  • Hose replacement made easy - the goose neck can easily be removed to simplify adding long lengths of hose to the reel.
  • Full flow stress free swivel design - The full flow swivel combines the highest grade seal design and materials with bearing areas to insure maximum service life.
  • Quality finish and corrosion resistant - Individually powder coated components offer the maximum protection from premature corrosion.
  • Easy to add tension - The T-handle tensioning device allows proper tension to be applied to the spool to eliminate the free spooling of the reel.

Reel Specifications
Part Number CA33118 L
Series 30000
Weight (lbs) 50
Hose I.D. (in) 3/4"
Hose O.D. (in) 1.075
Hose Length (ft) 175
Pressure (psi) 1000
Hose End (in)
Inlet (in) 3/4 NPT(F)
Reel Outlet (in) 3/4 NPT(F)
Hose Included No
Max Temperature (°F) 250
Fluid Path Materials
Seal Type Aflas
Swivel Material Steel
Shaft Material Steel
Gooseneck Material Ductile Iron


CA33118 L Dimensions


   Seal Material Compatibility Tables
